Semi Automatic Citrus Net Bag Packaging Machine Sweet Potato Orange
Mesh Bag Fruit Package Machine
Semi-Auto net bag packaging machine is simple to operate, packaging
weight from 250 grams to 5 kg. All kinds of fresh fruits and
vegetables, such as oranges, lemons, peppers, Brussels sprouts,
potatoes, Onions, garlic and other food products can be packaged
into net bags. The working principle of the net bag packaging
machine is that the net material is extracted from the network and
closed with a clamp. At the same time, the bag can be provided with
a label.
Semi-Auto Net Bags Packing Machine Application:
Semi-Auto Net Bags Packing Machine Features:
1.Utilizing a combination of two positioning gears and
proximityswitches allows for precise positioning of the push net.
2.It adopts LS inverter with reliable performance and
convenientoperation, Schneider PLC and touch screen electrical
control.
3.Adoption of Yadek pneumatic components with stable performance and
long service life.
4.Adopts automatic replacement of the mesh tube when the packing net
runs out.
Semi-Auto Net Bags Packing Machine Parameters:
Model | LS-DCF-1/G-20 |
Minimum Packing Weight | 3g |
Maximim PAcking Weight | 5000g |
Packging Speed | 25-40BPM |
Perimeter of Net Bag | 380/400mm |
Maximum Length of the Net Bag Installed on the Tube | 200m |
Machine Dimension | 1830mm*1128mm*1849mm |
Weight | 78kg |
High production efficiency:the machine adopts double cylinder
design, can alternately add mesh bags, the equipment can be
continuously produced without stopping.
Semi-Auto Net Bags Packing Machine Product Detail:
The company offers packaging lines for a wide variety of
commodities, including potatoes, Onions, citrus, stone fruits,
green beans, garlic, nuts, cherries, cherry/grape tomatoes,
carrots, kiwi and more. Our project engineers will work with you to
design your packaging line to maximize your available space,
production requirements and budget. We can supply all the elevator
conveyors, disc batchers and supporting equipment needed for a
complete production line.
Customization Solution:
According to your production line requirements, our experts will
provide you with an integrated weighing and packaging solution to
help you improve production efficiency.
